BeneVision N22/N19 Patient Monitor Operator’s Manual C - 7

C.4 Temperature Default Settings

C.5 NIBP Default Settings

PR Alarm switch ON

High limit Adult: 120

Pediatric: 160

Neonate: 200

Low limit Adult: 50

Pediatric: 75

Neonate: 100

Priority Med

Print on Alarm Off

Alarm Source Auto

PR Source Auto

QRS Volume General, OR: 2

Other departments: 0

Item Default Setting

T1, T2 Alarm switch On

High limit 38.0 °C

Low limit 35.0 °C

Priority Med

Print on Alarm Off

T Alarm switch On

High limit 2.0 °C

Priority Med

Print on Alarm Off

Item Default Setting

NIBP-S Alarm switch On

High limit Adult: 160 mmHg

Pediatric: 120 mmHg

Neonate: 90 mmHg

Low limit Adult: 90 mmHg

Pediatric: 70 mmHg

Neonate: 40 mmHg

Priority Med

Print on Alarm Off
