A - 2 BeneVision N22/N19 Patient Monitor Operator’s Manual
A.1 Monitor Safety Specifications
The monitor is classified, according to IEC 60601-1:
A.2 Physical Specifications
Degree of protection against electrical
shock
Type CF defibrillation proof for ECG, TEMP, IBP, SpO
2
C.O., PiCCO, NIBP, EEG,
and NMT
Type BF defibrillation proof for ScvO
2
, CO
2
, ICG, BIS, AG, RM, and rSO
2
Type of protection against electrical
shock
Class I
Degree of protection against harmful
ingress of water
IPX1
Degree of protection against hazards of
explosion
The equipment is not suitable for use in the presence of a flammable
anesthetic mixture with air with oxygen or nitrous oxide.
Mode of operation Continuous
Item Maximum
Weight (kg)
W × H × D (mm) Comments
N19 monitor
(main unit and
primary display
combinedly installed)
10.30 509 × 423 × 115
(display horizontally
installed)
584 × 348 × 115
(display vertically installed)
Including the battery, iview module, Wi-Fi
module, display with the handle and
navigation knob.
Excluding SMR, modules, and accessories.
N22 monitor
(main unit and
primary display
combinedly installed)
11.50 566 × 458 × 115
(display horizontally
installed)
641 × 383 × 115
(display vertically installed)
Including the battery, iview module, Wi-Fi
module, display with the handle and
navigation knob.
Excluding SMR, modules, and accessories.
Main unit 3.40 268 × 268 × 68 Including the battery.
Display, 19 inch 6.20 509 × 348 × 48 Excluding the handle.
Display, 22 inch 7.40 566 × 383 × 48 Excluding the handle.
Satellite module rack
(SMR)
2.30 403 × 221 × 145 Including the handle and cable hooks.
MPM module 0.63 136.5 × 80.5 × 102 /
SpO
2
module 0.26 136.5 × 40 × 102 Mindray SpO
2
,
C.O. module 0.25 136.5 × 40 × 102 /
IBP module 0.25 136.5 × 40 × 102 /
BIS module 0.25 136.5 × 40 × 102 /
ICG module 0.30 136.5 × 40 × 102 Medis ICG
CCO/SvO
2
module 0.25 136.5 × 40 × 102 /
PiCCO module 0.30 136.5 × 40 × 102 /
ScvO
2
module 0.25 136.5 × 40 × 102 /
EEG module 0.25 136.5 × 40 × 102 /
NMT module 0.30 136.5 × 40 × 102 /
rSO
2
module 0.30 136.5 × 40 × 102 /
