32 - 2 BeneVision N22/N19 Patient Monitor Operator’s Manual
32.1 Hemodynamics Introduction
This chapter introduces the hemodynamic parameters from the following modules:
■ PiCCO module
■ ScvO
2
module
■ CCO/SvO
2
module (measured from the Vigilance or Vigileo monitor)
For detailed information on hemodynamic-related parameter measurements and settings, see
21 Monitoring
Continuous Cardiac Output (CCO)
, 18 Monitoring Central Venous Oxygen Saturation (ScvO2), and 19
Monitoring CCO/SvO2
. This chapter only introduces the Hemodynamics menu.
32.2 Hemodynamic Parameters
32.2.1 Hemodynamic Parameters from PiCCO module and ScvO
2
module
The following table lists the hemodynamic parameters from the PiCCO module and ScvO
2
module.
Abbreviation Full Spelling Unit
Output CCO Continuous Cardiac Output L/min
CCI Continuous Cardiac Index L/min/m
2
SV Stroke Volume ml
SVI Stroke Volume Index ml/m
2
HR Heart Rate bpm
Contractility GEF Global Ejection Fraction %
CFI Cardiac Function Index L/min
dPmx Left Ventricular Contractility mmHg/s
Preload Volume GEDV Global End Diastolic Volume ml
GEDI Global End Diastolic Volume Index ml/m
2
ITBV Intrathoracic Blood Volume ml
ITBI Intrathoracic Blood Volume Index ml/m
2
SVV Stroke Volume Variation %
PPV Pulse Pressure Variation %
Afterload SVR Systemic Vascular Resistance DS/cm
5
or kPa-s/l
SVRI Systemic Vascular Resistance Index DS•m
2
/cm
5
or kPa-s-m
2
/l
pArt-M Mean Artery Pressure mmHg/kPa or cmH
2
O
pArt-D Diastolic Artery Pressure mmHg/kPa or cmH
2
O
pArt-S Systolic Artery Pressure mmHg/kPa or cmH
2
O
Organ Function EVLW Extravascular Lung Water ml
ELWI Extravascular Lung Water Index ml/kg
CPO Cardiac Power Output W
CPI Cardiac Power Index W/m
2
PVPI Pulmonary Vascular Permeability
Index
no unit
TB Blood Temperature ºC
