D - 16 BeneVision N22/N19 Patient Monitor Operator’s Manual

The display setup for XXX

is disabled.

(XX refers to the

parameter label)

Prompt / The parameter of the newly inserted module is

not displayed on the screen. Select a desired area

to display the parameter numerics and

waveforms. For more information, see

3.11.2 Displaying Parameter Numerics and

Waveforms

Alarm message Default priority

Indication on

alarm reset

Cause and solution
