Appendix H Component Details – Standard Models
346
Table 37 Language Switch Selection Pin Functions
SW6-2 IN1 (TB26-2) IN2 (TB26-3) IN3 (TB26-4) DESCRIPTION
OFF Pushbutton N/A N/A
Shorting IN1 to
GND advances
to next available
language
ON Hi Hi Hi Language #1
ON Low Hi Hi Language #2
ON Hi Low Hi Language #3
ON
Low
Low
Hi
Language #4
ON Hi Hi Low Language #5
ON Low Hi Low Language #6
ON Hi Low Low Language #7
ON Low Low Low Language #8
Table 38 Sensor Polarity Switch Settings
Switch
SENSOR
OFF
ON
LED
20
SW2-1
APPROACH SENSOR 1
ACTIVE LOW
ACTIVE HIGH
D18
SW2-2
APPROACH SENSOR 2
ACTIVE LOW
ACTIVE HIGH
D9
SW2-3 OCCUPIED SENSOR ACTIVE LOW ACTIVE HIGH D19
SW2-4 HAND SENSOR 1 ACTIVE LOW ACTIVE HIGH D10
SW3-1 HAND SENSOR 2 ACTIVE LOW ACTIVE HIGH D20
SW3-2 FOOT SENSOR 1 ACTIVE LOW ACTIVE HIGH D11
SW3-3 FOOT SENSOR 2 ACTIVE LOW ACTIVE HIGH D21
SW3-4
TOE SENSOR
ACTIVE LOW
ACTIVE HIGH
D12
SW4-1
HEAD SENSOR
ACTIVE LOW
ACTIVE HIGH
D22
SW4-2 BODY SENSOR ACTIVE LOW ACTIVE HIGH D13
SW4-3 GAS OK SENSOR ACTIVE LOW ACTIVE HIGH D23
SW4-4 SPARE 1 (UNLATCHED) ACTIVE LOW ACTIVE HIGH D14
SW5-1 SPARE 2 (UNLATCHED) ACTIVE LOW ACTIVE HIGH D15
SW5-2
SPARE 3 (LATCHED)
ACTIVE LOW
ACTIVE HIGH
D16
SW5-3
SPARE 4 (LATCHED)
ACTIVE LOW
ACTIVE HIGH
D17
SW5-4 FRISKER ACTIVE LOW ACTIVE HIGH D25
SW6-1 ALARM TEST ACTIVE LOW ACTIVE HIGH D24
SW6-2 LANGUAGE SELECTION ACTIVE LOW ACTIVE HIGH NO LED
20
LED indicator on the board is ON when associated signal is active
