ANSI Hardware Installation Manual 7360 ISAM FX-12 shelf cabling
Issue: 09 3HH-12893-AAAA-TCZZA 191
DRAFT
7 Route the other end of the VL cable to an NDLS-E card using the cable management tray
and the cable tie down clips to secure the cable as needed.
8 Connect the VL cable to the VL port on the NDLS-E card by removing the dust cover from
the VL port, removing the cap from the cable connector, and inserting the cable connector
into the VL port. The VL LEDs on the NDLS-E and NDPS-B cards should come on to indicate
that the link is active.
9 Repeat steps 3 to 8 for any additional VL cables that you want to connect between the NDPS-
B card and NDLS-E cards.
10 Re-install the shelf cover or covers removed in step 2.
11 STOP. This procedure is complete.
