Fiber optic cable management in the
7360 ISAM FX-4 shelf
390
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
6 Insert the fiber cables into the appropriate optical modules located on the front panels of the
NT and LT cards. If optical modules must first be installed, see Procedure 89.
7 Route and connect the other end of the fiber cables as per site practices.
8 STOP. This procedure is complete.
Procedure 89 Installing an optical module
To install optical modules, proceed as follows:
1 Put on an antistatic wrist strap and connect it to a grounding point.
2 Install an optical module as follows:
i Align the optical module with an optical module port and slide it into the port until it clicks
into place.
ii Remove the rubber cap from the optical module.
3 STOP. This procedure is complete.
Caution — It is important to install optical modules prior to connecting
power to a 7360 ISAM FX shelf.
Note — The optical module can only be removed when the pull-down
bar is released.
