DMTA-10040-01EN, Rev. E, February 2018
Specifications 335
External DC
supply
DC-IN voltage 24 VDC (60 W)
DC connector Circular, 2.5 mm pin diameter, center-positive
DC supply, external
(suggested
charger/adaptor
model)
EP-MCA-X (X indicates the power cord model;
see Table 14 on page 343)
Display Display size
(W × H, diagonal)
117.4 mm × 88.7 mm, 146.3 mm
(4.62in.×3.49in., 5.76in.)
Display resolution 640 × 480 pixels
Number of colors 256 colors
Display type Full VGA, color transflective LCD (liquid crystal
display)
Display viewing
angles
Horizontal: −80° to 80°
Vertical: −80° to 80°
Screen modes Normal or Full screen
Grid and display tools Choice of 5 grids (OFF, 10 × 10, FINE, COARSE,
and WEB) and user-selected crosshairs on single
and dual impedance plane views only
Display modes (all
possible)
Available display modes depend on instrument
model and selected operating mode. Available
displays are:
Single impedance plane (IMP)
Sweep display (SWEEP)
Combined impedance and sweep display
(SWP+IMP)
Dual impedance plane (DUAL IMP)
All-in-one display (ALL‑IN‑1) featuring up to
three configurable traces
Waterfall display for rotating scanner
(WATERFALL)
Input and
Outputs
USB One USB 2.0 peripheral port
Video output One standard VGA analog output port
Input/Output One 15-pin I/O port (male) with 6 analog
outputs, 4 alarm outputs (which can become
inputs), and 2 encoder signals (future expansion)
Table 8 General and environmental specifications (continued)
Category Parameter Va lue
