DMTA-10040-01EN, Rev. E, February 2018
Appendix A336
Eddy current
specifications
Probe types Absolute and differential, in either bridge or
reflection configuration. The instrument is fully
compatible with NORTEC PowerLink probes, as
well as other main probe and accessory
suppliers.
Probe connectors 16-pin LEMO and BNC
Balancing Internal automatic balancing for BNC connector
(absolute probes)
Number of probe
inputs
1
Frequency range 10 Hz to 12 MHz
Gain 0dB to 100dB in 0.1dB or 1dB increments
Rotation 0° to 359.9° in 0.1° or 1° increments
Sweep Variable from 0.005 s to 10 s per division (total of
13.3 divisions with FINE grid)
Low Pass filter 10 Hz to 2000 Hz and wide band
High Pass filter Off or 2 Hz to 1000 Hz, user-selectable in
constant Figure 6 or Figure 8 filter type
Continuous null (very
low frequency high-
pass filter)
0.2 Hz, 0.5 Hz, and 1.0 Hz
Probe drive LOW, MEDIUM and HIGH (2 volts, 5 volts, and
8volts)
Automatic Lift-Off Yes
Variable persistence 0.1 s to 10 s
Variable display erase 0.1 s to 60 s
Display modes Single Impedance, Sweep (strip chart), and Split
Screen.
Table 8 General and environmental specifications (continued)
Category Parameter Va lue
