Omron FQ2-S/CH Series User Manual

Adjusting the Images That Were Taken
FQ2-S/CH User’s Manual
101
3
Taking Images
Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be used as measurement data and output to external devices via Ethernet or used in
calculations. Measurement data can be specified for each filter item.
Parameter Setting Description
Common
(common RGB setting) Range: 0 to 255 (Default)
Set the upper and lower limit values of the background
suppression level. The same limits will be used for all
RGB colors.
The range from the specified lower to upper limits is
converted to 0 to 255.
Individual
(individual RGB settings)
Range: 0 to 255 (Default)
Set the upper and lower limit values of the background
suppression level for each RGB color.
The range from the specified lower to upper limits is
converted to 0 to 255.
Brightness range
(for Sensors with
Monochrome Cameras)
Range: 0 to 255 (Default) The specified range is converted to 0 to 255.
Expression t
ext string
Data name Description Data range
JG Judgement This is the judgment result.
-2: No judgement (not measured)
0: Judgement is OK
-1: Judgement is NG
