Adjusting the Images That Were Taken
132
FQ2-S/CH User’s Manual
• Source Image
You can select the image to which to apply the results of position compensation processing.
You can set the image for position compensation for each position compensation item.
[Image] − [Image adjustment] − [Linear Corr.] − [Modify]
1 Press [ ] − [Source image] at the right of the screen.
2 For the source image, select [Camera] or [Prev. image].
• Position Interpolation
You can select the precision of position compensation.
If you select [Bilinear], the precision of position compensation will increase.
[Image] − [Image adjustment] − [Linear Corr.] − [Modify]
1 Press [ ] − [Interpolation] at the right of the screen.
2 Select [Bilinear] or [None] for position interpolation.
• Measurement Data That Can Be Used for External Outputs and Calculations
You can use the values below as measurement data for external output and calculations.
Parameter Setting Description
Source image
Camera
The results of processing the position compensation item is applied to
the image that is taken by the Camera.
This setting is used when filter items or other position compensation
items have been used specifically for the position compensation item.
Prev. (Default)
This setting is used when the processing results of the current position
item are to be applied to the image that results from previous filter items
or other position compensation items.
Parameter Setting Description
Interpolation
Bilinear
(Default)
Points are connected with lines to find approximations. This create
smoother images.
When [Bilinear] is selected, the processing time increases.
None Position compensation is performed at the pixel level.
Expression
text string
Data name Description Data range
JG Judgement This is the judgement result.
-2: No judgement (not measured)
0: Judgement is OK
-1: Judgement is NG
