Calculations and Judgments Using Inspection Item Data
FQ2-S/CH User’s Manual
337
4
Setting Up Inspections
Edge Position
(FQ2-S1/S2/S3/S4 only)
Judgement JG
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
Position X X −99999.9999 to 99999.9999 0
Position Y Y −99999.9999 to 99999.9999 0
Ref. position X
(reference position X)
SX −99999.9999 to 99999.9999 0
Ref. position Y
(reference position Y)
SY −99999.9999 to 99999.9999 0
Offset amount DF −99999.9999 to 99999.9999 0
Edge Width
(FQ2-S1/S2/S3/S4 only)
Judgement
JG
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
D. edge width DF 0 to 99999.9999 0
Ref. edge width SW 0 to 99999.9999 0
Edge width W 0 to 99999.9999 0
Edge Pitch
(FQ2-S1/S2/S3/S4 only)
Judgement
JG
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
Edge pitch N 0 to 999 0
Average pitch P 0 to 99999.9999 0
Max. pitch (maximum pitch) PH 0 to 99999.9999 0
Min. pitch (minimum pitch) PL 0 to 99999.9999 0
Average width W 0 to 99999.9999 0
Max width (maximum width) WH 0 to 99999.9999 0
Min width (minimum width) WL 0 to 99999.9999 0
Color Data
(FQ2-S1/S2/S3/S4 only)
Judgement JG
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−10: Image error
−20: Other error
−2
R average AR 0 to 255 0
G average AG 0 to 255 0
B average AB 0 to 255 0
Color diff./dens. Av.
(color difference/density aver-
age)
AD Color difference: 0 to 442
Density average: 0 to 255
0
Clr deviat.
(color deviation/density devia-
tion)
DV Color difference: 0 to 221
Density deviation: 0 to 217
0
Inspection item Data name Expression
text string
Data range Default
