Omron FQ2-S/CH Series User Manual

Calculations and Judgments Using Inspection Item Data
338
FQ2-S/CH User’s Manual
Area
(FQ2-S1/S2/S3/S4 only)
Judgement JG
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
Area AR 0 to 999999999.9999 0
Gravity X X −99999.9999 to 99999.9999 0
Gravity Y Y −99999.9999 to 99999.9999 0
Reference area SA 0 to 999999999 0
Ref. position X
(reference position X)
SX −99999.9999 to 99999.9999 0
Ref. position Y
(reference position Y)
SY −99999.9999 to 99999.9999 0
Labeling
(FQ2-S1/S2/S3/S4 only)
Judgement JG
−2: No judgement (not measured)
0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
−2
Number of labels L 0 to 100 0
Area AR[0] to AR[99] 0 to 999999999.9999 0
Gravity X X[0] to X[99] −99999.9999 to 99999.9999 0
Gravity Y Y[0] to Y[99] −99999.9999 to 99999.9999 0
Reference area SA 0 to 999999999.9999 0
Ref. position X
(reference position X)
SX −99999.9999 to 99999.9999 0
Ref. position Y
(reference position Y)
SY −99999.9999 to 99999.9999 0
Total label area TAR 0 to 999999999.9999 0
Master angle ATH[0] to
ATH[99]
−180 to 180 0
Inspection item Data name Expression
text string
Data range Default
