System Configuration
FQ2-S/CH User’s Manual
33
2
Installation and Connections
*1: FQ2-S1and FQ2-S2re not supported.
*2: The shape and dimensions of the Ethernet connector plug and jack are specified in ISO/IEC8877:1992 (JIS X 5110:1996) and RJ-45 of the
FCC regulations. To prevent connector connection failures, the structure of the jack of this product does not allow insertion of plugs that do
not comply with the standard. If a commercially available plug cannot be inserted, it is likely that the plug is non-compliant.
Product Model number Remarks
FQ Sensor
FQ2-S-
FQ2-S-
FQ2-CH1M
This is the Sensor.
Touch Finder
FQ2-D This is a setup console.
PC Tool
---
The PC Tool can be used instead of the Touch Finder. If you
register as a member, you can download the free PC Tool as a
special service to purchasers.
Refer to the Member Registration Sheet that is enclosed with
the Sensor for the member registration procedure and the
download procedure for special member software.
Parallel Interface Sensor
Data Unit
*1
FQ-SDU1
You can connect a Sensor Data Unit to the I/O cable connec-
tor on the Sensor and connect the Parallel Interface Sensor
Data Unit to an external device. This allows you to output the
results of judgment conditions, measurements from inspection
items, and the results of expressions with parallel communica-
tions.
RS-232C Interface
Sensor Data Unit
*1
FQ-SDU2
You can connect a Sensor Data Unit to the I/O cable connec-
tor on the Sensor and connect the RS-232C Interface Sensor
Data Unit to an external device. This allows you to use no-pro-
tocol communications to send and receive commands, inspec-
tion item parameters, and other data between the Sensor and
the external control device that is connected with the RS-232C
cable. You can also use the ACK signal (parallel command
normal completion signal) for a parallel output from the Sensor
Data Unit.
FQ Ethernet Cable
FQ-WN0- Connects the Sensors to external devices such as the Touch
Finder, computers, and PLCs.
Standard RJ45
Ethernet Cable
*2
---
Connects the Switching Hub to the Touch Finder, computers,
and PLCs. Use a connector that complies with the FCC RJ45
standard. (STP (shielded twisted-pair) cable, category 5e or 6,
impedance: 100 Ω)
I/O Cable
FQ-WD0- Connects the Sensor to the power supply and external
devices.
Switching Hub
W4S1-0- Used to connect multiple Sensors to one Touch Finder or PC
Tool.
Sensor
Data Unit cable
FQ-WU0- This cable connects the FQ2-S3/S4/CH Sensor to the Sensor
Data Unit.
Parallel cable for FQ-SDU1
FQ-VP1- This cable connects the Parallel Interface Sensor Data Unit to
an external device.
Parallel cable for FQ-SDU2
FQ-VP2- This cable connects the RS-232C Interface Sensor Data Unit
to an external device.
RS-232C cable
(to connect to a PLC)
Recommended:
XW2Z-200S-V
(2 m) or XW2Z-500S-
V (5 m)
This cable connects the RS-232C Interface Sensor Data Unit
to an external device.
