Omron FQ2-S/CH Series

Menu Tables
446
FQ2-S/CH User’s Manual
Inspection
Settings
Teach
for 2D-code (DPM)*
3
Meas. Parameter
Cell (for
DataMatrix
and QR
Code only)
Sets the number of cells in the code.
For QR codes
21 × 21, 25 × 25, 29 × 29,
33 × 33, 37 × 37, 41 × 41,
45 × 45, 49 × 49, 53 × 53,
57 × 57, or Auto (defalut)
For square data matrices
10 × 10, 12 × 12, 14 ×14,
16 × 16, 18 × 18, 20 × 20,
22 × 22, 24 × 24, 26 × 26,
32 × 32, 36 × 36, 40 × 40,
44 × 44, 48 × 48, 52 × 52,
64 64, or Auto (Default)
For rectangular data matrices
8 × 18, 8 × 32,
12 × 26, 12 × 36,
16 × 36, 16 × 48, or Auto
Scene
Auto length
(Except for
when the
number of
cells is set to
automatic for
data matrices
or QR codes.)
Sets whether the code size is detected
automatically.
Yes (Default)
No
Scene
p. 210
Reverse Sets a normal or reverse image.
Normal
Reverse
Auto (Default)
Scene
Code color Sets the code color.
Black
White
Auto (Default)
Scene
Grid
correction
Set whether grid correction is ON or
OFF.
ON
OFF (Default)
Scene
Fast mode
Sets whether to use the Fast Mode.
Reading time is reduced if Fast Mode
is used.
Yes
No (Default) Scene
DPM print
quality
(Data
Matrix only)
Sets print quality evaluation ON/OFF.
ON
OFF (Default)
Scene
Timeout
Sets the timeout time for read pro-
cessing.
0 to 9999 ms (Default: 9999) Scene
Continuous test Same as [Continuous test] on the [Test] Tab Page. --- p. 340
Menu command Description Setting range Data
