Omron FQ2-S/CH Series

Menu Tables
FQ2-S/CH User’s Manual
447
Appendices
9
Inspection
Settings
Teach
(Search*
2
, Shape search II*
2
, Shape search lll*
2
, Sensitive search*
2
)
Model region
Used to specify the region of the
image to register as the model with a
combination of figures.
--- Scene
p. 224
p. 244
p. 225
Add
Rectangle
Ellipse
Wide circle
Polygon
Scene
p. 225
Delete --- Scene
Copy --- Scene ---
Console --- Scene p. 227
OR/NOT OR (Default)
NOT
Scene p. 226
One/All One (Default)
All
Scene ---
Insp. region
Adjusts the size and position of the
measurement region.
--- Scene p. 227
Detection point
You can specify which part of the
model to detect as coordinates during
inspections.
---
Scene p. 228
for Edge Position*
2
, Edge Width*
2
, and Edge Pitch*
2
Insp. region Adjusts the size and position of the
measurement region, changes the
measurement direction, etc.
--- Scene
p. 279
p. 285
p. 291
Edge Setting
Scene
p. 239
Mask size Select the pixel size to be used at
3×3(Default)
5×5
7×7
Edge level auto
The [Edge level] can be set automati-
cally by selecting ON. If edge recogni-
tion results are not good with this
setting, set to OFF.
ON (Default)
OFF
Edge level
This function will be enabled if you un-
check [Auto] check box.
Set the lower limit to recognize the
[Edge level]. Edges higher than set
value are recognized.
Decrease the setting value when it is
difficult to find edges.
Increase the setting value when the
effect of noise is high.
0 to 1024
(Default: 20)
Noise Removal
Level
Spesify the upper value to remove
noise.
0 to 100
(Default: 0)
Disp. Image
Selection Select the displayed image.
Meas. Img.
Meas. Img.+Model Img (Default)
Edge Image
Edge Img.+ Model Img.
Insp. region
Adjusts the size and position of the
measurement region, changes the
measurement direction, etc.
--- Scene
Color ON/OFF
(for Edge width
and Edge
position
Only)
Sets whether to specify an edge color. ON
OFF(Default)
p. 278
Menu command Description Setting range Data
