Menu Tables
FQ2-S/CH User’s Manual
453
Appendices
9
Inspection
Settings
Verification*
4
(OCR*
4
)
Matching Mode
Register the loaded strings to verify
with the specified string.
Direct Input (Default)
Calender Matching
Code Matching
Scene p. 148
Master data
regist.
(only Direct
Input)
Registers a character string in the
master data. Master data 0 to 31
OFF
Scene
p. 148
[MENU]
Auto
Reads a character string from an input
image and registers it in the master
data.
--- Scene
Insp.
region
Manual
L.1 to
L.4
A character string is entered directly in
the master data.
32 alphanumeric characters
Scene
Item ref.
Ref.
data
Registers the immediately preceding
read results as a verification character
string.
--- Scene
L.1 verif.
range to
L.4 verif.
range
Sets the beginning and end characters
to verify.
1 to 1024
(Defaults: beginning: 1, end: 1024) Scene
Copy Copies or clears registered master
data. --- --- ---
Delete
Auto teach No.
Sets the character string in the master
data in which to automatically register
the read result for teaching from an
external device.
OFF
Master data 0 to 31
Scene
Master data reg-
ist. (only Calen-
dar Matching)
Registers the Master data. --- Scene ---
L1 to L4 Enter the Master data. ---
Master data reg-
ist. (only Code
Matching)
Registers the Master data. --- ---
Master data
regist.
Registers the latest result as a verifi-
cation string.
--- Scene ---
Verif. Line
Select
Select the Line to verify. Check
Unchecked (Default)
Scene ---
Partial verif
L1 to L4
Set the beginning and end lines to ver-
ify.
1 to 1024
(Defaults: beginning: 1, end: 1024) Scene ---
Menu command Description Setting range Data
