Omron FQ2-S/CH Series

Menu Tables
458
FQ2-S/CH User’s Manual
Inspection
Details
(Sensitive search*
2
)
Model parameter
Rotation
Sets the angle range for the registered
model.
No (Default)
Yes
Scene p. 266
Angle range
−180 to 180
(Defaults: Lower limit: −180
Upper limit: 180)
Scene p. 266
Sub-model num-
ber
You can change the number of divi-
sions of the registered model.
3 × 3
5 × 5 (Default)
9 × 9
Scene p. 265
Plain inspection Enables or disables inspecting plain
sections.
Yes
No (Default)
Scene p. 214
Meas. Parameter
Sub-pixel You can increase the accuracy of
measurement positioning.
No (Default)
Yes
Scene p. 264
Candidate level
Sets the detection target to only
objects with a correlation above the
specified candidate level.
0 to 100 (Default: 70) Scene p. 264
Output parameter
Reflect
You can specify whether to reflect the
judgement results of an inspection
item in the overall judgement.
No
Yes (Default) Scene p. 263
(Edge width*
2
, Edge position*
2
, Edge pitch*
2
)
Meas. Parameter
Edge level
(Color image
only)
Sets the color density level of the
edge.
Color difference (%):
0 to 100 (Default: 50)
Color difference: 0 to 442 (Default: 20)
Scene
p. 275
p. 266
p. 276
Noise level
(Color image
only)
Sets the color density level to treat as
noise.
0 to 442 (Default: 5)
Scene
p. 275
p. 266
p. 276
Measurement
method (mono-
chrome image
only)
Specifies the edge detection method. Projection (Default)
Differentiation
Scene
p. 275
p. 266
p. 276
Density change
(monochrome
image only)
Specifies the density direction that is
detected.
Light to Dark (Default)
Dark to Light
Scene p. 275
p. 266
p. 276
Edge level
(monochrome
image only)
Specifies the density level that is
regarded as an edge.
Density diff. (%): 0 to 100 (Default: 50)
Density diff.: 0 to 255 (Default: 20) Scene
p. 275
p. 266
p. 276
Noise level
(monochrome
image only)
Specifies the density change level that
is regarded as an edge. 0 to 255 (Default: 5) Scene
p. 275
p. 266
p. 276
Output parameter
Reflect
You can specify whether to reflect the
judgment results of an inspection item
in the overall judgment.
No
Yes (Default) Scene
p. 275
p. 266
p. 276
(Color Data*
2
)
Output parameter
Reflect
You can specify whether to reflect the
judgement results of an inspection
item in the overall judgement.
No
Yes (Default) Scene
Menu command Description Setting range Data
