Omron FQ2-S/CH Series

Menu Tables
460
FQ2-S/CH User’s Manual
*1 Refer to FQ2-S/CH Series User's Manual for Communications Settings (Cat. No. Z338).
*2 Not supported on the FQ2-CH Series.
*3 Not supported on the FQ2-S1/S2/S3 Series or FQ2-CH Series.
*4 Not supported on the FQ2-S1/S2/S3 Series.
Calculation
Settings
Expression
[MENU]
Expression 0 to
expression 31
Sets the number of the expression for
which to set a calculation.
--- Scene
p. 323
Expression set-
tings
Sets the expressions. --- Scene
Data Uses the measurement result of other
items.
Inspection item
calculation symbols ( ( ) / * . , + TJG)
Scene p. 330
Const. Inputs constants or mathematical
operators.
0 to 9, ., calculation symbol
( ( ) / * ? , + TJG)
Scene p. 330
Math. Uses functions in expressions.
SIN, COS,
ATAN, AND,
OR, NOT
ABS, MAX,
MIN, MOD,
SQRT, ANGL
(angle of straight line joining two points
(center of gravity and model center)),
DIST (distance between two points),
calculation symbols ( ( ) / * . , + TJG)
Scene p. 330
Rename Deletes/copies the expression or
changes the expression name.
--- Scene
p. 330
Copy --- ---
Delete --- ---
Judgement Specifies the parameters for judgment
of results.
Scene p. 323
Details
Output parameter
Reflect
You can specify whether to reflect the
judgment results of a calculation in the
overall judgment.
No
Yes (Default) Scene p. 323
Retry details
Max Count
(Normal retry)
Sets the number of retries. 0 to 20
Default: 4
Scene
---*
1
Interval
(Normal retry)
Sets the retry interval (msec). 32 to 999
Default: 100
Scene
Brightness step or Shutter
speed step
(Exposure retry)
Sets the exposure time step (msec). Brightness step: 1 to 20, Default 5
shutter speed step:
0.01 to 1.00 (Default: 0.30)
Scene
Increment count
(Exposure retry)
Sets the increment count for the
brightness (shutter speed) step.
0 to 10
(Default: 2)
Scene
Decrement count
(Exposure retry)
Sets the decrement count for the
brightness (shutter speed) step.
0 to 10
(Default: 2)
Scene
Menu command Description Setting range Data
