Omron FQ2-S/CH Series - Page 554

Specifications and Dimensions
552
FQ2-S/CH User’s Manual
Environ-
mental
immunity
Ambient tem-
perature range
Operating: 0 to 50°C
Storage: −25 to 65°C
(with no icing or condensation)
Ambient humid-
ity range
Operating and storage: 35% to 85% (with no condensation)
Ambient atmo-
sphere
No corrosive gas
Vibration resis-
tance (destruc-
tion)
10 to 150 Hz, single amplitude: 0.35 mm, X/Y/Z directions
8 min each, 10 times
Shock resis-
tance (destruc-
tion)
150 m/s
2
3 times each in 6 direction (up, down, right, left, forward, and backward)
Degree of pro-
tection
IEC 60529 IP67 (Except when Polarizing Filter Attachment is mounted
or connector cap is removed.)
IEC 60529 IP40
Materials Sensor: PBT, PC, SUS
Mounting Bracket: PBT
Polarizing Filter Attachment: PBT, PC
Ethernet connector: Oil-resistance vinyl compound
I/O connector: Lead-free heat-resistant PVC
Cover: Zinc-plated steel,
Thickness: 0.6 mm
Case: Aluminum diecast
alloy (ADC-12)
Mounting base: Polycarbon-
ate ABS
Weight Depends on field of view and installation distance. Refer to Table 1. Approx. 160 g without base,
Approx. 185 g with base
Accessories Mounting Bracket (FQ-XL)(1)
Polarizing Filter Attachment (FQ-XF1) (1)
Instruction Manual
Member Registration Sheet
Mounting Base (1)
Four Mounting Screws (M3×8
mm)(4)
Instruction Manual
Member Registration Sheet
LED class
*2
Risk Group 2 ---
Item Inspection and ID models
Model NPN FQ2-S40 FQ2-
S40-M
FQ2-
S40-08
FQ2-
S40-08M
FQ2-S40-13 FQ2-S40-
13M
PNP FQ2-S45 FQ2-
S45-M
FQ2-
S4508
FQ2-
S45-08M
FQ2-S45-13 FQ2-S45-
13M
