Omron FQ2-S/CH Series

Specifications and Dimensions
FQ2-S/CH User’s Manual
557
Appendices
9
Dimensions
FQ2-S10010F/-S10050F
FQ2-S15010F/-S15050F
FQ2-S20010F/-S20050F
FQ2-S25010F/-S25050F
(Unit: mm)
FQ2-S40010F/-S40010F-M/-S40050F/-S40050F-M
FQ2-S45010F/-S45010F-M/-S45050F/-S45010F-M
FQ2-CH10010F-M/-CH10050F-M
FQ2-CH15010F-M/-CH15050F-M
FQ2-S30010F-08/-S35010F-08/-S30010F-08M/-S35010F-08M
FQ2-S30050F-08/-S35050F-08/-S30050F-08M/-S35050F-08M
FQ2-S40010F-08/-S45010F-08/-S40010F-08M/-S45010F-08M
FQ2-S40050F-08/-S45050F-08/-S40050F-08M/-S45050F-08M
1
38
11
(57)
90
(108)
(18)
20±0.1
46
45
67
44
20
20
38
42
(25)
8
32 9
ptical
xis
Mounting hole dimensions
Tightening torque: 1.2 N·m
4-M4
Depth: 6
1/4-20UNC
Depth: 6
The mounting bracket can be attached to any side
Two, 4.5 dia.
