Page #558 background imageLoading...
Page #558 background image
Specifications and Dimensions
556
FQ2-S/CH User’s Manual
Table 1
*1: Tolerance: ±10% max.
*2: Applicable standards:IEC62471-2
Table 2
*3: Do not allow the load current to exceed 50 mA. The output circuit may be damaged if the load current exceeds 50 mA.
Accessories Mounting Bracket (FQ-XL)(1)
Polarizing Filter Attachment (FQ-XF1) (1)
Instruction Manual
Member Registration Sheet
LED class
*2
Risk Group 2
350,000-pixel Models Field of view
(H×V) *1
Installation dis-
tance
Num-
ber of
LEDs
Weight
NPN PNP
FQ2-CH10010F-M FQ2-CH15010F-M 7.5 × 4.7 to
13 × 8.2 mm
38 to 57 mm 4 Approx.
160 g
FQ2-CH10050F-M FQ2-CH15050F-M 13 × 8.2 to
53 × 33 mm
56 to 215 mm 4
FQ2-CH10100F-M FQ2-CH15100F-M 53 × 33 to
240 × 153 mm
220 to 970 mm 8
Approx.
150 g
FQ2-CH10100N-M FQ2-CH15100N-M 29 × 18 to
300 × 191 mm
32 to 380 mm 8
Item NPN PNP
Input specifi-
cations
ON: Shorted to 0 V, or 1.5 V max.
OFF: Open (leakage current: 0.1 mA max.)
ON: Shorted to power supply voltage, or power supply volt-
age −1.5 V max.
OFF: Open (leakage current: 0.1 mA max.)
Output speci-
fications
*3
NPN open collector
30 VDC, 50 mA max., residual voltage: 2.0 V max.
PNP open collector
30 VDC, 50 mA max., residual voltage: 2.0 V max.
Item Inspection and ID models
Model NPN FQ2-CH10-M
PNP FQ2-CH15--M
