Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 16 SERIAL INTERFACE IICA
R01UH0368EJ0210 Rev.2.10 1070
Dec 10, 2015
(2) Slave device operation (slave address data reception)
(a) Start ~ Address ~ Data ~ Data ~ Stop
(i) When WTIM0 = 0
1: IICS0 = 0001×110B
2: IICS0 = 0001×000B
3: IICS0 = 0001×000B
4: IICS0 = 00000001B
Remark : Always generated
: Generated only when SPIE0 = 1
×: Don’t care
(ii) When WTIM0 = 1
1: IICS0 = 0001×110B
2: IICS0 = 0001×100B
3: IICS0 = 0001××00B
4: IICS0 = 00000001B
Remark : Always generated
: Generated only when SPIE0 = 1
×: Don’t care
ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP
3 4 2
1
ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP
3 4 2
1
