RL78/F13, F14 CHAPTER 16 SERIAL INTERFACE IICA
R01UH0368EJ0210 Rev.2.10 1080
Dec 10, 2015
(ii) When WTIM0 = 1
1: IICS0 = 0110×010B
2: IICS0 = 0010×110B
3: IICS0 = 0010×100B
4: IICS0 = 0010××00B
5: IICS0 = 00000001B
Remark : Always generated
: Generated only when SPIE0 = 1
×: Don’t care
(6) Operation when arbitration loss occurs (no communication after arbitration loss)
When the device is used as a master in a multi-master system, read the MSTS0 bit each time interrupt request signal
INTIICA0 has occurred to check the arbitration result.
(a) When arbitration loss occurs during transmission of slave address data (when WTIM0 = 1)
1: IICS0 = 01000110B
2: IICS0 = 00000001B
Remark : Always generated
: Generated only when SPIE0 = 1
ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP
3 4 5 2
1
ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP
2
1

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
