RL78/F13, F14 CHAPTER 16 SERIAL INTERFACE IICA

R01UH0368EJ0210 Rev.2.10 1082

Dec 10, 2015

(ii) When WTIM0 = 1

1: IICS0 = 10001110B

2: IICS0 = 01000100B

3: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1

(d) When loss occurs due to restart condition during data transfer

(i) Not extension code (Example: unmatches with SVA0)

1: IICS0 = 1000×110B

2: IICS0 = 01000110B

3: IICS0 = 00000001B

Remark : Always generated

: Generated only when SPIE0 = 1

×: Don’t care

n = 6 to 0

ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP

3 2

ST AD6 to AD0 R/W ACK D7 to Dn AD6 to AD0 ACK SPST R/W D7 to D0 ACK

3 2
