RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 259
Dec 10, 2015
Table 4-12. Setting Functions of P70/ANI26 to P74/ANI30 Pins
ADPC Register PM7 Register ADS Register P70/ANI26 to P74/ANI30 Pins
Digital I/O selection Input mode

Digital input
Output mode

Digital output
Analog input selection Input mode Selects ANI. Analog input (to be converted)
Does not select ANI. Analog input (not to be converted)
Output mode Selects ANI. Setting prohibited
Does not select ANI.
Reset signal generation sets P70/ANI26 to P74/ANI30 to analog input mode.
