RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 260

Dec 10, 2015

Figures 4-41 to 4-48 show block diagrams of port 7 for 100-pin products.

Figure 4-41. Block Diagram of P70

P70/TI15/SI11/

INTP8/TO15/

KR0/SDA11/

SNZOUT4/ANI26

PORT

PU70

P70

P-ch

PU7

PM7

POM70

POM7

POM

PM70

PIM7

PIM70

PIM

PMC

PMC7

PMC70

PMS

PMS0

SDA11

TO05/SNZOUT4

CMOS

(Schmitt3)

TTL

CMOS

(Schmitt1)

PITHL7

PITHL70

PITHL

Internal bus

Output latch

Alternate function

TI15/SI11/SDA11

/INTP8/KR0

Alternate function

Selector

A/D converter

ADS

ADS4 to ADS0
