RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 286

Dec 10, 2015

Figure 4-59. Block Diagram of P106

PORT

PU10

PM10

P10

PM106

P106

PU106

PMS

PMS0

P-ch

P106/(LTXD1)

Internal bus

Output latch

Alternate function

(LTXD1)

Selector

P10: Port register 10

PM10: Port mode register 10

PMS: Port mode select register

PU10: Pull-up resistor option register 10

RD: Read signal

WRxx: Write signal
