RL78/F13, F14 CHAPTER 8 TIMER RD
R01UH0368EJ0210 Rev.2.10 604
Dec 10, 2015
Figure 8-34. Format of Timer RD General Registers Ai, Bi, Ci, and Di (TRDGRAi, TRDGRBi, TRDGRCi, TRDGRDi)
(i = 0 or 1) [Output Compare Function]
Address: F0278H (TRDGRA0), F027AH (TRDGRB0), After Reset: FFFFH
Note
FFF58H (TRDGRC0), FFF5AH (TRDGRD0),
F0288H (TRDGRA1), F028AH (TRDGRB1),
FFF5CH (TRDGRC1), FFF5EH (TRDGRD1)
Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TRDGRAi — — — — — — — — — — — — — — — —
TRDGRBi
TRDGRCi
TRDGRDi
— Function R/W
Bits 15 to 0 See Table 8-4 TRDGRji Register Functions in Output Compare Function. R/W
Note The value after reset is undefined when FRQSEL4 = 1 in the user option byte (000C2H/020C2H) and TRD0EN =
0 in the PER1 register. If it is necessary to read the initial value, set f
CLK to fIH and TRD0EN = 1 before reading.
Table 8-4. TRDGRji Register Functions in Output Compare Function
Register Setting Register Function Output-Compare
Output Pin
TRDBFji IOj3
TRDGRAi — — General register. Write the compare value. TRDIOAi
TRDGRBi TRDIOBi
TRDGRCi 0 1 General register. Write the compare value. TRDIOCi
TRDGRDi TRDIODi
TRDGRCi 1 1 Buffer register. Write the next compare value
(see 8. 3. 1 (2) Buffer Operation).
TRDIOAi
TRDGRDi TRDIOBi
TRDGRCi 0 0 TRDIOAi output
control
(See 8. 3. 3 (2) Changing Output Pins
in Registers TRDGRCi (i = 0 or 1) and
TRDGRDi.)
TRDIOAi
TRDGRDi TRDIOBi output
control
TRDIOBi
Caution When the setting of bits TCK2 to TCK0 in the TRDCRi register is 000B (f
CLK, fIH, fPLL, fSUB, and fIL) and
the compare value is set to 0000H, a request signal to the data transfer controller (DTC) and the event
link controller (ELC) is generated only once immediately after the count starts. When the compare
value is 0001H or higher, a request signal is generated each time a compare match occurs.
Remark i = 0 or 1, j = A, B, C, or D
TRDBFji: Bit in TRDMR register, IOj3: Bit in TRDIORCi register
To Next Page
