RL78/F13, F14 CHAPTER 8 TIMER RD

R01UH0368EJ0210 Rev.2.10 609

Dec 10, 2015

Figure 8-38. Format of Timer RD General Registers Ai, Bi, Ci, and Di (TRDGRAi, TRDGRBi,TRDGRCi, TRDGRDi)

(i = 0 or 1) [PWM3 Mode]

Address: F0278H (TRDGRA0), F027AH (TRDGRB0), After Reset: FFFFH

Note

FFF58H (TRDGRC0), FFF5AH (TRDGRD0),

F0288H (TRDGRA1), F028AH (TRDGRB1),

FFF5CH (TRDGRC1), FFF5EH (TRDGRD1)

Symbol 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

TRDGRAi — — — — — — — — — — — — — — — —

TRDGRBi

TRDGRCi

TRDGRDi

— Function R/W

Bits 15 to 0 See Table 8-8 TRDGRji Register Functions in PWM3 Mode. R/W

Note The value after reset is undefined when FRQSEL4 = 1 in the user option byte (000C2H/020C2H) and TRD0EN =

0 in the PER1 register. If it is necessary to read the initial value, set f

CLK to fIH and TRD0EN = 1 before reading.
