RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT
R01UH0368EJ0210 Rev.2.10 837
Dec 10, 2015
(2) Operation procedure
Figure 15-26. Initial Setting Procedure for Master Transmission
Remark m: Unit number (m = 0, 1), n: Channel number (n = 0, 1), mn = 00, 01, 10, 11
Set an operation mode, etc.
Starting initial setting
Setting the PER0 register
Setting the SPSm register
Setting the SMRmn register
Setting the SCRmn register
Setting the SDRmn register
Setting the SOm register
Changing setting of the SOEm register
Setting port
Writing to the SSm register
Starting communication
Release the serial array unit from the
reset status and start clock supply.
Set the operation clock.
Set a communication format.
Set the initial output level of the serial clock
(CKOmn) and serial data (SOmn).
Set the SOEmn bit to 1 and enable data
output of the target channel.
Enable data output and clock output of
the target channel by setting a port
register and port mode register.
Set transmit data to the SDRmn registe
and start communication.
Set the SSmn bit of the target channel to 1
and set the SEmn bit to 1 (to enable
operation).
Set a transfer baud rate.
To Next Page
