RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT

R01UH0368EJ0210 Rev.2.10 870

Dec 10, 2015

(3) Processing flow (in single-transmission mode)

Figure 15-53. Timing Chart of Slave Transmission (in Single-Transmission Mode)

(Type 1: DAPmn = 0, CKPmn = 0)

Remark m: Unit number (m = 0, 1), n: Channel number (n = 0, 1), p: CSI number (p = 00, 01, 10, 11),

mn = 00, 01, 10, 11

SSmn

SEmn

SDRmn

SCKp pin

SOp pin

Shift

INTCSIp

TSFmn

STmn

Data transmission (8-bit length)

Transmit data 3

Transmit data 2

Transmit data 1

Transmit data 2

Transmit data 3

Shift operation
