General-purpose timers (TIM15/TIM16/TIM17) RM0351
1128/1830 DocID024597 Rev 5
32.6.16 TIM16 option register 1 (TIM16_OR1)
Address offset: 0x50
Reset value: 0x0000
32.6.17 TIM16 option register 2 (TIM16_OR2)
Address offset: 0x60
Reset value: 0x0000 0001
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res
1514131211109876543210
Res Res Res Res Res Res Res Res Res Res Res Res Res Res TI1_RMP[1:0]
rw rw
Bits 31:2 Reserved, must be kept at reset value.
Bits1:0 TI1_RMP[1:0]: Input capture 1 remap
00: TIM16 input capture 1 is connected to I/O
01: TIM16 input capture 1 is connected to LSI
10: TIM16 input capture 1 is connected to LSE
11: TIM16 input capture 1 is connected to RTC wakeup interrupt
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res
1514131211109876543210
Res Res Res Res
BKCM
P2P
BKCM
P1P
BKINP
BKDF1
BK1E
Res Res Res Res Res
BKCM
P2E
BKCM
P1E
BKINE
rw rw rw rw rw rw rw
Bits 31:12 Reserved, must be kept at reset value.
Bit 11 BKCMP2P: BRK COMP2 input polarity
This bit selects the COMP2 input sensitivity. It must be programmed together with the BKP
polarity bit.
0: COMP2 input is active low
1: COMP2 input is active high
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Bit 10 BKCMP1P: BRK COMP1 input polarity
This bit selects the COMP1 input sensitivity. It must be programmed together with the BKP
polarity bit.
0: COMP1 input is active low
1: COMP1 input is active high
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
