Power control (PWR) RM0351
184/1830 DocID024597 Rev 5
5.4.5 Power status register 1 (PWR_SR1)
Address offset: 0x10
Reset value: 0x0000 0000. This register is not reset when exiting Standby modes and with
the PWRRST bit in the RCC_APB1RSTR1 register.
Access: 2 additional APB cycles are needed to read this register vs. a standard APB read.
Bits 31:10 Reserved, must be kept at reset value.
Bit 9 VBRS: V
BAT
battery charging resistor selection
0: Charge V
BAT
through a 5 kOhms resistor
1: Charge V
BAT
through a 1.5 kOhms resistor
Bit 8 VBE: V
BAT
battery charging enable
0: V
BAT
battery charging disable
1: V
BAT
battery charging enable
Bits 7:5 Reserved, must be kept at reset value.
Bit 4 WP5: Wakeup pin WKUP5 polarity
This bit defines the polarity used for an event detection on external wake-up pin, WKUP5
0: Detection on high level (rising edge)
1: Detection on low level (falling edge)
Bit 3 WP4: Wakeup pin WKUP4 polarity
This bit defines the polarity used for an event detection on external wake-up pin, WKUP4
0: Detection on high level (rising edge)
1: Detection on low level (falling edge)
Bit 2 WP3: Wakeup pin WKUP3 polarity
This bit defines the polarity used for an event detection on external wake-up pin, WKUP3
0: Detection on high level (rising edge)
1: Detection on low level (falling edge)
Bit 1 WP2: Wakeup pin WKUP2 polarity
This bit defines the polarity used for an event detection on external wake-up pin, WKUP2
0: Detection on high level (rising edge)
1: Detection on low level (falling edge)
Bit 0 WP1: Wakeup pin WKUP1 polarity
This bit defines the polarity used for an event detection on external wake-up pin, WKUP1
0: Detection on high level (rising edge)
1: Detection on low level (falling edge)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
WUFI Res. Res. Res. Res. Res. Res. SBF Res. Res. Res. WUF5 WUF4 WUF3 WUF2 WUF1
r r rrrrr
