RM0351
80/1830 DocID024597 Rev 5
Table 2. STM32L496xx/4A6xx devices memory map and peripheral register boundary
addresses
(1)
Bus Boundary address
Size
(bytes)
Peripheral Peripheral register map
AHB4 0xA000 1000 - 0xA000 13FF 1 KB QUADSPI
Section 17.6.14: QUADSPI register
map
AHB3
0xA000 0400 - 0xA000 0FFF 3KB Reserved -
0xA000 0000 - 0xA000 03FF 1 KB FMC Section 16.7: FMC register map
- 0x5006 0C00 - 0x5FFF FFFF ~260 MB Reserved -
AHB2
0x5006 0800 - 0x5006 0BFF 1 KB RNG Section 27.8.4: RNG register map
0x5006 0400 - 0x5006 07FF 1 KB HASH Section 29.6.8: HASH register map
0x5006 0000 - 0x5006 03FF 1 KB AES Section 28.14.18: AES register map
0x5005 0400 - 0x5005 FFFF 62 KB Reserved -
0x5005 0000 - 0x5005 03FF 1 KB DCMI Section 20.7.12: DCMI register map
0x5004 0400 - 0x5004 FFFF 62 KB Reserved -
0x5004 0000 - 0x5004 03FF 1 KB ADC Section 18.7.4: ADC register map
0x5000 0000 - 0x5003 FFFF 16 KB OTG_FS
Section 47.15.54: OTG_FS register
map
0x4800 2400 - 0x4FFF FFFF ~127 MB Reserved -
0x4800 2000 - 0x4800 23FF 1 KB GPIOI Section 8.4.13: GPIO register map
0x4800 1C00 - 0x4800 1FFF 1 KB GPIOH Section 8.4.13: GPIO register map
0x4800 1800 - 0x4800 1BFF 1 KB GPIOG Section 8.4.13: GPIO register map
0x4800 1400 - 0x4800 17FF 1 KB GPIOF Section 8.4.13: GPIO register map
0x4800 1000 - 0x4800 13FF 1 KB GPIOE Section 8.4.13: GPIO register map
0x4800 0C00 - 0x4800 0FFF 1 KB GPIOD Section 8.4.13: GPIO register map
0x4800 0800 - 0x4800 0BFF 1 KB GPIOC Section 8.4.13: GPIO register map
0x4800 0400 - 0x4800 07FF 1 KB GPIOB Section 8.4.13: GPIO register map
0x4800 0000 - 0x4800 03FF 1 KB GPIOA Section 8.4.13: GPIO register map
-
0x4002 BC00 - 0x47FF FFFF ~127 MB Reserved -
