DocID024597 Rev 5 79/1830
RM0351
92
APB1
0x4000 5000 - 0x4000 53FF 1 KB UART5
Section 40.8.12: USART
register map
0x4000 4C00 - 0x4000 4FFF 1 KB UART4
Section 40.8.12: USART
register map
0x4000 4800 - 0x4000 4BFF 1 KB USART3
Section 40.8.12: USART
register map
0x4000 4400 - 0x4000 47FF 1 KB USART2
Section 40.8.12: USART
register map
0x4000 4000 - 0x4000 43FF 1KB Reserved -
0x4000 3C00 - 0x4000 3FFF 1 KB SPI3 Section 42.6.8: SPI register map
0x4000 3800 - 0x4000 3BFF 1 KB SPI2 Section 42.6.8: SPI register map
0x4000 3400 - 0x4000 37FF 1KB Reserved -
0x4000 3000 - 0x4000 33FF 1 KB IWDG
Section 36.4.6: IWDG register
map
0x4000 2C00 - 0x4000 2FFF 1 KB WWDG
Section 37.4.4: WWDG register
map
0x4000 2800 - 0x4000 2BFF 1 KB RTC
Section 38.6.21: RTC register
map
0x4000 2400 - 0x4000 27FF 1 KB LCD
Section 25.6.6: LCD register
map
0x4000 1800 - 0x4000 2400 3KB Reserved -
0x4000 1400 - 0x4000 17FF 1 KB TIM7
Section 33.4.9: TIM6/TIM7
register map
0x4000 1000 - 0x4000 13FF 1 KB TIM6
Section 33.4.9: TIM6/TIM7
register map
0x4000 0C00- 0x4000 0FFF 1 KB TIM5
Section 31.4.23: TIMx register
map
0x4000 0800 - 0x4000 0BFF 1 KB TIM4
Section 31.4.23: TIMx register
map
0x4000 0400 - 0x4000 07FF 1 KB TIM3
Section 31.4.23: TIMx register
map
0x4000 0000 - 0x4000 03FF 1 KB TIM2
Section 31.4.23: TIMx register
map
Table 1. STM32L475xx/476xx/486xx devices memory map and peripheral register boundary
addresses (continued)
Bus Boundary address Size (bytes) Peripheral Peripheral register map
