ST STM32L4 5 Series User Manual

DocID024597 Rev 5 81/1830
RM0351
92
AHB1
0x4002 B000 - 0x4002 BBFF 3 KB DMA2D Section 12.5.24: DMA2D register map
0x4002 4400 - 0x4002 AFFF 26 KB Reserved -
0x4002 4000 - 0x4002 43FF 1 KB TSC Section 26.6.11: TSC register map
0x4002 3400 - 0x4002 3FFF 1KB Reserved -
0x4002 3000 - 0x4002 33FF 1 KB CRC Section 15.4.6: CRC register map
0x4002 2400 - 0x4002 2FFF 3KB Reserved -
0x4002 2000 - 0x4002 23FF 1 KB
FLASH
registers
Section 3.7.17: FLASH register map
0x4002 1400 - 0x4002 1FFF 3KB Reserved -
0x4002 1000 - 0x4002 13FF 1 KB RCC Section 6.4.33: RCC register map
0x4002 0800 - 0x4002 0FFF 2KB Reserved -
0x4002 0400 - 0x4002 07FF 1 KB DMA2 Section 11.5.9: DMA register map
0x4002 0000 - 0x4002 03FF 1 KB DMA1 Section 11.5.9: DMA register map
APB2
0x4001 6400 - 0x4001 FFFF 39 KB Reserved -
0x4001 6000 - 0x4001 63FF 1 KB DFSDM1 Section 24.8.16: DFSDM register map
0x4001 5C00 - 0x4001 5FFF 1KB Reserved -
0x4001 5800 - 0x4001 5BFF 1 KB SAI2 Section 43.5: SAI registers
0x4001 5400 - 0x4001 57FF 1 KB SAI1 Section 43.5: SAI registers
0x4001 4C00 - 0x4001 53FF 2KB Reserved -
0x4001 4800 - 0x4001 4BFF 1 KB TIM17
Section 32.6.20: TIM16/TIM17 register
map
0x4001 4400 - 0x4001 47FF 1 KB TIM16
Section 32.6.20: TIM16/TIM17 register
map
0x4001 4000 - 0x4001 43FF 1 KB TIM15 Section 32.5.20: TIM15 register map
0x4001 3C00 - 0x4001 3FFF 1KB Reserved -
0x4001 3800 - 0x4001 3BFF 1 KB USART1 Section 40.8.12: USART register map
0x4001 3400 - 0x4001 37FF 1 KB TIM8 Section 30.4.31: TIM8 register map
0x4001 3000 - 0x4001 33FF 1 KB SPI1 Section 42.6.8: SPI register map
0x4001 2C00 - 0x4001 2FFF 1 KB TIM1 Section 30.4.30: TIM1 register map
0x4001 2800 - 0x4001 2BFF 1 KB SDMMC1 Section 45.8.16: SDMMC register map
0x4001 2000 - 0x4001 27FF 2KB Reserved -
0x4001 1C00 - 0x4001 1FFF 1 KB FIREWALL Section 4.4.8: Firewall register map
0x4001 0800- 0x4001 1BFF 5KB Reserved -
0x4001 0400 - 0x4001 07FF 1 KB EXTI Section 14.5.13: EXTI register map
Table 2. STM32L496xx/4A6xx devices memory map and peripheral register boundary
addresses
(1)
(continued)
Bus Boundary address
Size
(bytes)
Peripheral Peripheral register map
