ST STM32L4 5 Series User Manual

RM0351
82/1830 DocID024597 Rev 5
APB2
0x4001 0200 - 0x4001 03FF
1 KB
COMP Section 22.6.3: COMP register map
0x4001 0030 - 0x4001 01FF VREFBUF
Section 21.3.3: VREFBUF register
map
0x4001 0000 - 0x4001 002F SYSCFG Section 9.2.12: SYSCFG register map
APB1
0x4000 9800 - 0x4000 FFFF 26 KB Reserved -
0x4000 9400 - 0x4000 97FF 1 KB LPTIM2 Section 34.7.11: LPTIM register map
0x4000 8C00 - 0x4000 93FF 2KB Reserved -
0x4000 8800 - 0x4000 8BFF 1 KB SWPMI1
Section 44.6.10: SWPMI register map
and reset value table
0x4000 8400 - 0x4000 87FF 1 KB I2C4 Section 39.7.12: I2C register map
0x4000 8000 - 0x4000 83FF 1 KB LPUART1
Section 41.7.10: LPUART register
map
0x4000 7C00 - 0x4000 7FFF 1 KB LPTIM1 Section 34.7.11: LPTIM register map
0x4000 7800 - 0x4000 7BFF 1 KB OPAMP Section 23.5.7: OPAMP register map
0x4000 7400 - 0x4000 77FF 1 KB DAC Section 19.5.21: DAC register map
0x4000 7000 - 0x4000 73FF 1 KB PWR
Section 5.4.26: PWR register map and
reset value table
0x4000 6C00 - 0x4000 6FFF 1KB Reserved -
0x4000 6800 - 0x4000 6BFF 1 KB CAN2 Section 46.9.5: bxCAN register map
0x4000 6400 - 0x4000 67FF 1 KB CAN1 Section 46.9.5: bxCAN register map
0x4000 6000 - 0x4000 63FF 1 KB CRS Section 7.6.5: CRS register map
0x4000 5C00- 0x4000 5FFF 1 KB I2C3 Section 39.7.12: I2C register map
0x4000 5800 - 0x4000 5BFF 1 KB I2C2 Section 39.7.12: I2C register map
0x4000 5400 - 0x4000 57FF 1 KB I2C1 Section 39.7.12: I2C register map
0x4000 5000 - 0x4000 53FF 1 KB UART5 Section 40.8.12: USART register map
0x4000 4C00 - 0x4000 4FFF 1 KB UART4 Section 40.8.12: USART register map
Table 2. STM32L496xx/4A6xx devices memory map and peripheral register boundary
addresses
(1)
(continued)
Bus Boundary address
Size
(bytes)
Peripheral Peripheral register map
