Basic timers (TIM6/TIM7) RM0351
1144/1830 DocID024597 Rev 5
33.4.4 TIM6/TIM7 status register (TIMx_SR)
Address offset: 0x10
Reset value: 0x0000
33.4.5 TIM6/TIM7 event generation register (TIMx_EGR)
Address offset: 0x14
Reset value: 0x0000
33.4.6 TIM6/TIM7 counter (TIMx_CNT)
Address offset: 0x24
Reset value: 0x0000
1514131211109876543210
Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res UIF
rc_w0
Bits 15:1 Reserved, must be kept at reset value.
Bit 0 UIF: Update interrupt flag
This bit is set by hardware on an update event. It is cleared by software.
0: No update occurred.
1: Update interrupt pending. This bit is set by hardware when the registers are updated:
– At overflow or underflow regarding the repetition counter value and if UDIS = 0 in the
TIMx_CR1 register.
– When CNT is reinitialized by software using the UG bit in the TIMx_EGR register, if URS = 0
and UDIS = 0 in the TIMx_CR1 register.
1514131211109876543210
Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res UG
w
Bits 15:1 Reserved, must be kept at reset value.
Bit 0 UG: Update generation
This bit can be set by software, it is automatically cleared by hardware.
0: No action.
1: Re-initializes the timer counter and generates an update of the registers. Note that the
prescaler counter is cleared too (but the prescaler ratio is not affected).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
UIF
CPY
Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res
r
1514131211109876543210
CNT[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
