DocID024597 Rev 5 1479/1830
RM0351 Serial audio interface (SAI)
1490
43.5.3 Configuration register 2 (SAI_ACR2 / SAI_BCR2)
Address offset: Block A: 0x008
Address offset: Block B: 0x028
Reset value: 0x0000 0000
Bit 4 Reserved, must be kept at reset value
Bits 3:2 PRTCFG[1:0]: Protocol configuration
These bits are set and cleared by software. These bits have to be configured when the audio block is
disabled.
00: Free protocol. Free protocol allows to use the powerful configuration of the audio block to
address a specific audio protocol (such as I2S, LSB/MSB justified, TDM, PCM/DSP...) by setting
most of the configuration register bits as well as frame configuration register.
01: SPDIF protocol
10: AC’97 protocol
11: Reserved
Bits 1:0 MODE[1:0]: SAIx audio block mode
These bits are set and cleared by software. They must be configured when SAIx audio block is
disabled.
00: Master transmitter
01: Master receiver
10: Slave transmitter
11: Slave receiver
Note: When the audio block is configured in SPDIF mode, the master transmitter mode is forced
(MODE[1:0] = 00). In Master transmitter mode, the audio block starts generating the FS and the
clocks immediately.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
COMP[1:0] CPL MUTECNT[5:0]
MUTE
VAL
MUTE TRIS
F
FLUSH
FTH
rw rw rw rw rw rw rw rw rw rw rw rw w rw rw rw
