Example of configuration
To output a simple value to the TPIU:
• Configure the TPIU and assign TRACE I/Os by configuring the DBGMCU_CR (refer to
Section 48.17.2: TRACE pin assignment and Section 48.16.3: Debug MCU
configuration register (DBGMCU_CR))
• Write 0xC5ACCE55 to the ITM Lock Access Register to unlock the write access to the
ITM registers
• Write 0x00010005 to the ITM Trace Control Register to enable the ITM with
Synchronous enabled and an ATB ID different from 0x00
• Write 0x1 to the ITM Trace Enable Register to enable the Stimulus Port 0
• Write 0x1 to the ITM Trace Privilege Register to unmask Stimulus Ports 7:0
• Write the value to output in the Stimulus Port Register 0: this can be done by software
(using a printf function)
@E0000E80 ITM trace control
Bits 31-24 = Always 0
Bits 23 = Busy
Bits 22-16 = 7-bits ATB ID which identifies the source of the
trace data
Bits 15-10 = Always 0
Bits 9:8 = TSPrescale = Time Stamp Prescaler
Bits 7-5 = Reserved
Bit 4 = SWOENA = Enable SWV behavior (to clock the
timestamp counter by the SWV clock)
Bit 3 = DWTENA: Enable the DWT Stimulus
Bit 2 = SYNCENA: this bit must be to 1 to enable the DWT to
generate synchronization triggers so that the TPIU can then
emit the synchronization packets
Bit 1 = TSENA (Timestamp Enable)
Bit 0 = ITMENA: Global Enable Bit of the ITM
@E0000E40 ITM trace privilege
Bit 3: mask to enable tracing ports31:24
Bit 2: mask to enable tracing ports23:16
Bit 1: mask to enable tracing ports15:8
Bit 0: mask to enable tracing ports7:0
@E0000E00 ITM trace enable
Each bit enables the corresponding Stimulus port to generate
trace
@E0000000-
E000007C
Stimulus port
registers 0-31
Write the 32-bits data on the selected Stimulus Port (32
available) to be traced out
Table 320. Main ITM registers (continued)
