ST STM32L4 5 Series User Manual

DocID024597 Rev 5 385/1830
RM0351 Chrom-Art Accelerator™ controller (DMA2D)
391
12.5.16 DMA2D output memory address register (DMA2D_OMAR)
Address offset: 0x003C
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
MA[31:16]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
MA[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31: 0 MA[31: 0]: Memory Address
Address of the data used for the output FIFO. These bits can only be written when data
transfers are disabled. Once the transfer has started, they are read-only.
The address alignment must match the image format selected e.g. a 32-bit per pixel
format must be 32-bit aligned and a 16-bit per pixel format must be 16-bit aligned.
