DocID024597 Rev 5 591/1830
RM0351 Analog-to-digital converters (ADC)
614
18.6.5 ADC configuration register 2 (ADC_CFGR2)
Address offset: 0x10
Reset value: 0x0000 0000
Bit 2 DFSDMCFG: DFSDM mode configuration
This bit is set and cleared by software to enable the DFSDM mode. It is effective only when
DMAEN=0.
0: DFSDM mode disabled
1: DFSDM mode enabled
Note: To make sure no conversion is ongoing, the software is allowed to write this bit only when
ADSTART= 0 and JADSTART= 0.
Bit 1 DMACFG: Direct memory access configuration
This bit is set and cleared by software to select between two DMA modes of operation and is
effective only when DMAEN=1.
0: DMA One Shot mode selected
1: DMA Circular mode selected
For more details, refer to Section : Managing conversions using the DMA
Note: Software is allowed to write this bit only when ADSTART=0 and JADSTART=0 (which ensures
that no conversion is ongoing).
In dual-ADC modes, this bit is not relevant and replaced by control bit DMACFG of the
ADC_CCR register.
Bit 0 DMAEN: Direct memory access enable
This bit is set and cleared by software to enable the generation of DMA requests. This allows to use
the GP-DMA to manage automatically the converted data. For more details, refer to Section :
Managing conversions using the DMA.
0: DMA disabled
1: DMA enabled
Note: Software is allowed to write this bit only when ADSTART=0 and JADSTART=0 (which ensures
that no conversion is ongoing).
In dual-ADC modes, this bit is not relevant and replaced by control bits MDMA[1:0] of the
ADC_CCR register.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res.
ROV
SM
TROVS OVSS[3:0] OVSR[2:0] JOVSE ROVSE
rw rw rw rw rw rw rw rw rw rw rw
