DocID024597 Rev 5 605/1830
RM0351 Analog-to-digital converters (ADC)
614
18.6.21 ADC Differential mode Selection Register (ADC_DIFSEL)
Address offset: 0xB0
Reset value: 0x0000 0000
18.6.22 ADC Calibration Factors (ADC_CALFACT)
Address offset: 0xB4
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. DIFSEL[18:16]
rrr
1514131211109876543210
DIFSEL[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw r
Bits 31:19 Reserved, must be kept at reset value.
Bits 18:16 DIFSEL[18:16]: Differential mode for channels 18 to 16.
These bits are read only. These channels are forced to single-ended input mode (either connected to
a single-ended I/O port or to an internal channel).
Bits 15:1 DIFSEL[15:1]: Differential mode for channels 15 to 1
These bits are set and cleared by software. They allow to select if a channel is configured as single
ended or differential mode.
DIFSEL[i] = 0: ADC analog input channel-i is configured in single ended mode
DIFSEL[i] = 1: ADC analog input channel-i is configured in differential mode
Note: Software is allowed to write these bits only when the ADC is disabled (ADCAL=0,
JADSTART=0, JADSTP=0, ADSTART=0, ADSTP=0, ADDIS=0 and ADEN=0).
It is mandatory to keep cleared ADC1_DIFSEL[15] (connected to an internal single ended
channel)
Bit 0 DIFSEL[0]: Differential mode for channel 0
This bit is read only. This channel is forced to single-ended input mode (connected to an internal
channel).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. CALFACT_D[6:0]
rw rw rw rw rw rw rw
151413121110987654321 0
Res. Res. Res. Res. Res. Res. Res. Res. Res. CALFACT_S[6:0]
rw rw rw rw rw rw rw
