18.7.2 ADC common control register (ADC_CCR)
Address offset: 0x08 (this offset address is relative to the master ADC base address +
0x300)
Reset value: 0x0000 0000
Bit 2 EOC_MST: End of regular conversion of the master ADC
This bit is a copy of the EOC bit in the corresponding ADC_ISR register.
Bit 1 EOSMP_MST: End of Sampling phase flag of the master ADC
This bit is a copy of the EOSMP bit in the corresponding ADC_ISR register.
Bit 0 ADRDY_MST: Master ADC ready
This bit is a copy of the ADRDY bit in the corresponding ADC_ISR register.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res.
CH18
SEL
CH17
SEL
VREF
EN
PRESC[3:0] CKMODE[1:0]
rw rw rw rw rw rw rw rw rw
15141312111098 7 654321 0
MDMA[1:0]
DMA
CFG
Res. DELAY[3:0] Res. Res. Res. DUAL[4:0]
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:25 Reserved, must be kept at reset value.
Bit 24 CH18SEL: CH18 selection
This bit is set and cleared by software to control the channel 18 of ADC1 and ADC3
0: V
BAT
channel disabled.
1: V
BAT
channel enabled
Bit 23 CH17SEL: CH17 selection
This bit is set and cleared by software to control the channel 17 of ADC1 and ADC3
0: Temperature sensor channel disabled
1: Temperature sensor channel enabled
Bit 22 VREFEN: V
REFINT
enable
This bit is set and cleared by software to enable/disable the V
REFINT
channel.
0: V
REFINT
channel disabled
1: V
REFINT
channel enabled
