ST STM32L4 5 Series User Manual

DocID024597 Rev 5 77/1830
RM0351
92
APB2
0x4001 4800 - 0x4001 4BFF 1 KB TIM17
Section 32.6.20: TIM16/TIM17
register map
0x4001 4400 - 0x4001 47FF 1 KB TIM16
Section 32.6.20: TIM16/TIM17
register map
0x4001 4000 - 0x4001 43FF 1 KB TIM15
Section 32.6.20: TIM16/TIM17
register map
0x4001 3C00 - 0x4001 3FFF 1KB Reserved -
0x4001 3800 - 0x4001 3BFF 1 KB USART1
Section 40.8.12: USART
register map
0x4001 3400 - 0x4001 37FF 1 KB TIM8
Section 30.4.31: TIM8 register
map
0x4001 3000 - 0x4001 33FF 1 KB SPI1 Section 42.6.8: SPI register map
0x4001 2C00 - 0x4001 2FFF 1 KB TIM1
Section 30.4.30: TIM1 register
map
0x4001 2800 - 0x4001 2BFF 1 KB SDMMC1
Section 45.8.16: SDMMC
register map
0x4001 2000 - 0x4001 27FF 2KB Reserved -
0x4001 1C00 - 0x4001 1FFF 1 KB FIREWALL
Section 4.4.8: Firewall register
map
0x4001 0800- 0x4001 1BFF 5KB Reserved -
0x4001 0400 - 0x4001 07FF 1 KB EXTI
Section 14.5.13: EXTI register
map
0x4001 0200 - 0x4001 03FF
1 KB
COMP
Section 22.6.3: COMP register
map
0x4001 0030 - 0x4001 01FF VREFBUF
Section 21.3.3: VREFBUF
register map
0x4001 0000 - 0x4001 002F SYSCFG
Section 9.2.12: SYSCFG
register map
Table 1. STM32L475xx/476xx/486xx devices memory map and peripheral register boundary
addresses (continued)
Bus Boundary address Size (bytes) Peripheral Peripheral register map
