RM0351 Liquid crystal display controller (LCD)
787
1/2
028x2
-
COM[3:2] not used
COM[1:0] COM[1:0]
SEG[43:40]/SEG[31:28]/COM[7:4] not used
SEG[27:0] SEG[27:0]
132x2
COM[3:2] not used
COM[1:0] COM[1:0]
SEG[43:40]/SEG[31:28]/COM[7:4] SEG[31:28]
SEG[27:0] SEG[27:0]
STATIC
0
-
44x1
COM[3:1] not used
COM0 COM0
SEG[43:40]/SEG[31:28]/COM[7:4] SEG[43:40]
SEG[39:0] SEG[39:0]
140x1
COM[3:1] not used
COM0 COM0
SEG[43:40]/SEG[31:28]/COM[7:4] SEG[31:28]
SEG[39:32] SEG[39:32]
SEG[31:28] not used
SEG[27:0] SEG[27:0]
028x1
-
COM[3:1] not used
COM0 COM0
SEG[43:40]/SEG[31:28]/COM[7:4] not used
SEG[27:0] SEG[27:0]
132x1
COM[3:1] not used
COM0 COM0
SEG[43:40]/SEG[31:28]/COM[7:4] SEG[31:28]
SEG[27:0] SEG[27:0]
Table 162. Remapping capability (continued)
Configuration bits SEG x COM
Output pin Function
DUTY MUX_SEG
