ST STM32L4 5 Series User Manual

DocID024597 Rev 5 787/1830
RM0351 Liquid crystal display controller (LCD)
787
Refer to Section 2.2.2 on page 75 for the Register boundary addresses table.
0x44
LCD_RAM
(COM6)
S31 S30 S29 S28 S27 S26 S25 S24 S23 S22 S21 S20 S19 S18 S17 S16 S15 S14 S13 S12
S11
S10 S09 S08 S07 S06 S05 S04 S03 S02 S01 S00
00000000000000000000000000000000
0x48
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
S39 S38 S37 S36 S35 S34 S33 S32
00000000000000000000000000000000
0x4C
LCD_RAM
(COM7)
S31 S30 S29 S28 S27 S26 S25 S24 S23 S22 S21 S20 S19 S18 S17 S16 S15 S14 S13 S12
S11
S10 S09 S08 S07 S06 S05 S04 S03 S02 S01 S00
00000000000000000000000000000000
0x50
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
S39 S38 S37 S36 S35 S34 S33 S32
00000000000000000000000000000000
Table 165. LCD register map and reset values (continued)
Offset
Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
