Touch sensing controller (TSC) RM0351
804/1830 DocID024597 Rev 5
26.6.10 TSC I/O group x counter register (TSC_IOGxCR) (x = 1..8)
Address offset: 0x30 + 0x04 x Analog I/O group number
Reset value: 0x0000 0000
Bits 31:24 Reserved, must be kept at reset value.
Bits 23:16 GxS: Analog I/O group x status
These bits are set by hardware when the acquisition on the corresponding enabled analog I/O
group x is complete. They are cleared by hardware when a new acquisition is started.
0: Acquisition on analog I/O group x is ongoing or not started
1: Acquisition on analog I/O group x is complete
Note: When a max count error is detected the remaining GxS bits of the enabled analog I/O
groups are not set.
Bits 15:8 Reserved, must be kept at reset value.
Bits 7:0 GxE: Analog I/O group x enable
These bits are set and cleared by software to enable/disable the acquisition (counter is
counting) on the corresponding analog I/O group x.
0: Acquisition on analog I/O group x disabled
1: Acquisition on analog I/O group x enabled
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. CNT[13:0]
rrrrrrrrrrrrrr
Bits 31:14 Reserved, must be kept at reset value.
Bits 13:0 CNT[13:0]: Counter value
These bits represent the number of charge transfer cycles generated on the analog I/O group
x to complete its acquisition (voltage across C
S
has reached the threshold).
