SYSMEX SF-3000 User Manual

MAINTENANCE & SUPPLIES, As Needed, Clean Manual Rinse Mech.
5-30 Sysmex SF-3000 Operator's Manual -- Revised September 1995
(5) Rinse the manual rinse cup with tap water.
Figure 5-7-3: Rinse the Rinse Cup
(6) Use a dry gauze to wipe the rinse cup.
(7) Reconnect the two tubes (arrows ① and ➁). Then replace the manual rinse cup to
its original position (arrow ➂). The smaller diameter tube should route behind the
rinse cup mechanism.
Manual Rinse
Cup
2
3
1
Figure 5-7-4: Reconnect the Tubes
(8) Gently insert the pipette into the manual rinse cup and push up the rinse cup
mechanism to the uppermost position.
CAUTION: • To prevent the manual aspiration pipette from bending, gently
insert the pipette into the manual rinse cup.
• To prevent a "Rinse Motor Function Error", make sure that the
rinse cup mechanism is at its uppermost position.
(9) Turn ON the power.
(10) Record the cleaning on the maintenance check list.
